ENGINE
M6060, M7060, WSM
1-S5
Valve Bridge Arm to Valve Bridge Shaft
• Valve Bridge Arm
• Valve Bridge Shaft
Oil Clearance
I.D.
O.D.
0.018 to 0.057 mm
0.00071 to 0.0022 in.
9.050 to 9.080 mm
0.3563 to 0.3574 in.
9.023 to 9.032 mm
0.3553 to 0.3555 in.
0.015 mm
0.0059 in.
–
–
Push Rod Alignment – 0.25 mm
0.0099 in.
Tappet to Tappet Bore
• Tappet
• Tappet Bore
Oil Clearance
O.D.
I.D.
0.020 to 0.050 mm
0.00079 to 0.0019 in.
9.965 to 9.980 mm
0.3924 to 0.3929 in.
10.000 to 10.015 mm
0.39370 to 0.39429 in.
0.07 mm
0.003 in.
–
–
Timing Gear
• Crank Gear to Cam Gear
• Cam Gear to Balancer 1 Gear
• Cam Gear to Idle Gear
• Idle Gear to Supply Pump Gear
• Idle Gear to Balancer 2 Gear
Backlash
Backlash
Backlash
Backlash
Backlash
0.041 to 0.139 mm
0.0016 to 0.0055 in.
0.041 to 0.134 mm
0.0016 to 0.0053 in.
0.041 to 0.134 mm
0.0016 to 0.0053 in.
0.041 to 0.134 mm
0.0016 to 0.0053 in.
0.041 to 0.129 mm
0.0016 to 0.0051 in.
0.22 mm
0.0087 in.
0.22 mm
0.0087 in.
0.22 mm
0.0087 in.
0.22 mm
0.0087 in.
0.22 mm
0.0087 in.
Idle Gear Side Clearance 0.15 to 0.25 mm
0.0059 to 0.0098 in.
0.90 mm
0.035 in.
Idle Gear Shaft to Idle Gear Bushing
• Idle Gear Shaft
• Idle Gear Bushing
Oil Clearance
O.D.
I.D.
0.0250 to 0.106 mm
0.000985 to 0.00417 in.
46.959 to 46.975 mm
1.8488 to 1.8494 in.
47.000 to 47.065 mm
1.8504 to 1.8529 in.
0.11 mm
0.0043 in.
–
–
Camshaft Side Clearance
Alignment
–
–
0.10 mm
0.0039in.
0.01 mm
0.0004 in.
Cam Height Intake
Exhaust
37.50 mm
1.476 in.
37.90 mm
1.492 in.
37.00 mm
1.457 in.
37.40 mm
1.472 in.
Item Factory Specification Allowable Limit
