wsm M7060 - Page 169

ENGINE
M6060, M7060, WSM
1-S8
LUBRICATING SYSTEM
COOLING SYSTEM
PREPARATION
9Y1210828ENS0002US0
Item Factory Specification Allowable Limit
Engine Oil Pressure At Idle Speed
At Rated Speed
–
200 to 390 kPa
2.0 to 4.0 kgf/cm
2
29 to 56 psi
50 kPa
0.5 kgf/cm
2
7 psi
150 kPa
1.5 kgf/cm
2
21 psi
Inner Rotor to Outer Rotor Clearance 0.030 to 0.090 mm
0.0012 to 0.0035 in.
0.30 mm
0.012 in.
Outer Rotor to Pump Body Clearance 0.100 to 0.184 mm
0.00394 to 0.00724 in.
0.30 mm
0.012 in.
Inner Rotor to Cover Clearance 0.025 to 0.075 mm
0.00099 to 0.0029 in.
0.225 mm
0.00886 in.
Relief Valve Spring Free Length 60.0 to 60.5 mm
2.37 to 2.38 in.
55.0 mm
2.17 in.
Item Factory Specification Allowable Limit
Fan/Alternator Belt (ROPS Model) Tension 16 to 17 mm / 98 N
0.63 to 0.68 in. / 98 N
(10 kgf, 22 lbf)
–
Fan/Alternator Belt (CABIN Model) Tension 11 to 12 mm / 98 N
0.44 to 0.47 in. / 98 N
(10 kgf, 22 lbf)
–
Alternator Belt Tension 10 to 12 mm / 98 N
0.40 to 0.47 in. / 98 N
(10 kgf, 22 lbf)
–
Radiator Cap Air Leakage 10 seconds or more
88 → 59 kPa
0.9 → 0.6 kgf/cm
2
13 → 9 psi
–
Radiator Water Tightness Water tightness at
specified pressure
137 kPa
1.4 kgf/cm
2
20 psi
–
Thermostat Valve Opening
Temperature
Valve Full Opening
Temperature
(Opened
Completely)
74.5 to 78.5 °C
166.1 to 173.3 °F
90 °C
194 °F
–
–
Item Factory Specification Allowable Limit
Battery Positive Terminal Clearance 1.0 to 1.5 mm
0.040 to 0.059 in.
–
KiSC issued 08, 2013 A
