TRANSMISSION
M6060, M7060, WSM
2-S4
Lever Pin to Lever Bushing
• Lever Pin
• Lever Bushing
Clearance
O.D.
I.D.
0.049 to 0.156 mm
0.0019 to 0.0061 in.
13.957 to 13.984 mm
0.5495 to 0.5506 in.
14.033 to 14.113 mm
0.5525 to 0.5556 in.
0.5 mm
0.0197 in.
–
–
Internal Circlip to Belleville Washer
(Cupped Spring Washer)
Clearance 1.8 to 2.0 mm
0.071 to 0.079 in.
3.6 mm
0.142 in.
Shuttle Clutch Steel Plate Thickness 3.1 to 3.3 mm
0.122 to 0.130 in.
–
Shuttle Clutch Pressure Plate Thickness 4.42 to 4.58 mm
0.174 to 0.180 in.
–
Clutch Disc for Shuttle Clutch
(3C151-23030)
Thickness 3.30 to 3.40 mm
0.130 to 0.133 in.
–
Clutch Disc for Shuttle Clutch
(3C151-23130)
Thickness 3.15 to 3.25 mm
0.124 to 0.127 in.
–
4WD Clutch Disc Thickness 1.9 to 2.1 mm
0.075 to 0.082 in.
1.7 mm
0.067 in.
4WD Steel Plate Thickness 1.7 to 1.9 mm
0.067 to 0.074 in.
1.5 mm
0.059 in.
4WD Pressure Plate Thickness 3.70 to 3.90 mm
0.146 to 0.153 in.
3.50 mm
0.138 in.
4WD Piston Flatness – 0.15 mm
0.006 in.
4WD Steel Plate Flatness – 0.40 mm
0.016 in.
4WD Pressure Plate Flatness – 0.30 mm
0.012 in.
Seal Ring for 4WD Clutch Pack Thickness 2.39 to 2.44 mm
0.0941 to 0.0960 in.
2.0 mm
0.079 in.
PTO Clutch Disc Thickness 2.2 mm
0.087 in.
1.8 mm
0.071 in.
PTO Steel Plate Thickness 1.95 to 2.05 mm
0.0768 to 0.0807 in.
1.80 mm
0.071 in.
PTO Piston Flatness – 0.15 mm
0.006 in.
PTO Steel Plate Flatness – 0.30 mm
0.012 in.
PTO Return Spring Free Length 42.5 to 43.5 mm
1.68 to 1.71 in.
37.5 mm
1.48 in.
Seal Ring for PTO Clutch Pack Thickness 2.4 to 2.5 mm
0.095 to 0.098 in.
2.0 mm
0.079 in.
Spiral Bevel Pinion Shaft Only Turning Torque 2.94 to 3.43 N·m
0.3 to 0.35 kgf·m
2.2 to 2.5 lbf·ft
–
Spiral Bevel Gear to Spiral Bevel Pinion
Shaft
Backlash 0.2 to 0.3 mm
0.0079 to 0.0118 in.
0.4 mm
0.016 in.
