FRONT AXLE
M6060, M7060, WSM
5-S3
9Y1210828FAS0002US0
Bevel Gear in Bevel Gear Case Backlash 0.20 to 0.30 mm
0.0079 to 0.011 in.
0.4 mm
0.02 in.
Bevel Gear in Front Wheel Case Backlash 0.20 to 0.30 mm
0.0079 to 0.011 in.
0.4 mm
0.02 in.
Internal Gear to Planetary Gear Backlash 0.10 to 0.30 mm
0.0040 to 0.011 in.
0.5 mm
0.02 in.
Planetary Gear to Shaft
• Planetary Gear
•Shaft
• Needle Bearing
Clearance
I.D.
O.D.
O.D.
0.0090 to 0.046 mm
0.00036 to 0.0018 in.
33.009 to 33.025 mm
1.2993 to 1.3001 in.
24.991 to 25.000 mm
0.98390 to 0.98425 in.
3.994 to 4.000 mm
0.1573 to 0.1574 in.
0.3 mm
0.01 in.
–
–
–
Thrust Collar Thickness 0.75 to 0.85 mm
0.030 to 0.033 in.
0.5 mm
0.02 in.
Item Factory Specification Allowable Limit
