CABIN
M6060, M7060, WSM
9-S53
Before Replacing Windshields (2)
1. When the Sika Tack-Ultrafast or equivalent attached to the
cabin frame and the glass are reused, remove the bond clearly.
2. Clean the frame surface with Sika-cleaner No. 1.
• Remove the bond completely.
9Y1210828CAS0097US0
Before Replacing Windshields (3)
1. Check that the glasses are not damaged and cracked.
2. Turn over the glass and clean this surface of the glass by
Sika-cleaner No. 1.
3. The cleaning area of the rear surface is indicated "a" in the
figure left.
• If not cleaning the glass, it may result in adhesive failure.
9Y1210828CAS0098US0
(1) Upper Windshield
(2) Lower Windshield (Left)
(3) Lower Windshield (Right)
a: 25 mm (0.98 in.)
To Next Page
