GENERAL
M6060, M7060, WSM
G-43
Cleaning Master Cylinder Filter
1. Remove the master cylinder hose (2) from the master cylinder
assembly (1).
2. Remove the filter (3) using the screwdriver.
3. Clean the filer (3) with kerosene and blow with air.
9Y1210828GEG0065US0
Replacing Master Cylinder Kit
1. To check and adjusting for brake pedal. (See page 4-S4.)
9Y1210828GEG0066US0
Replacing Equalizer Kit
• To check and adjusting for brake pedal. (See page 4-S4.)
9Y1210828GEG0067US0
Replacing Brake Seal 1 and 2
• To check and adjusting for brake pedal. (See page 4-S4.)
9Y1210828GEG0068US0
Replacing Parking Brake Cable
• To check and adjusting for parking brake cable. (See page
4-S8.)
9Y1210828GEG0069US0
Tightening torque
Master cylinder hose
retaining nut
22.6 to 27.5 N·m
2.31 to 2.80 kgf·m
16.7 to 20.2 lbf·ft
(1) Master Cylinder Assembly
(2) Master Cylinder Hose
(3) Filter
To Next Page
