Floor Space Requirements
WARNING
This product will produce ozone during
operation. The ozone that is produced is
dependent on the print volume and is heavier
than air. Providing the correct environmental
parameters as specified in Xerox installation
procedures will ensure that concentration
levels meet safe limits
• The minimum space requirement is 116.75
inches (292 cm).x 85 inches (212.5 cm).
USO Only: If additional information concerning
ozone is needed, request the Xerox publication
600P83222, Ozone by calling 1-800-828-6571.
43,5"
(108 cm)
Figure 2. IOT Dimensions
Install the Printer
1. Prepare to remove the internal packing
material from the Printer.
a. Remove all external shipping tape.
b. Loosen the two locking screws and open
the Rear Door.
c. Raise and latch the Top Cover.
d. Lower the Media Transport Cover.
e. Hold open the Developer Module Door
while lifting and removing the Developer
Module Side Cover.
2. (Figure 4): Remove the cable tie from the
Stripper Finger Assembly.
1
Lift Stripper Bar slightly
Cut and remove cable
tie ,
24"
Allow bar to return to
normal position
Fuser Heat Roll
R3020K
Figure 4. Removing the Cable Tie
Figure 3. Minimum Space Requirements
Installation
1/98
6-16
8830
To Next Page
