February 2013
6-26
ColorQube® 9303 Family
GP 7
General Procedures/Information
Figure 6 Rear frame connection
• Figure 7, registration / preheat internal ground. Check the reg/preheat assembly internal
ground wire terminals. If necessary disconnect and clean the contact faces then re-install.
Figure 7 Reg/preheat assembly connections
Ground wire
Ground contact
Ground contact
Plate ground contacts
Ground contact
Ground contact
Plate ground contacts
