Xerox ColorQube 9301 Service Manual

February 2013
6-140
ColorQube® 9303 Family
dC131
General Procedures/Information
450-010 PFP Min Sheet
Count BTW
Retries
The minimum number of
sheets PFP has to feed after it
attempted extra pick retries
(more than 2 tries), before it
can run extra retries again.
Range= 0 to
4,294,967,295
10,000
450-011 TTM1 Extra Pick
Retries
Set to 1 to allow a extra pick
retries TTM1
Range = 0 to 1 1
450-012 TTM2 Extra Pick
Retries
Set to 1 to allow a extra pick
retries TTM2.
Range = 0 to 1 1
450-013 TTM3 Extra Pick
Retries
Set to 1 to allow a extra pick
retries TTM3.
Range = 0 to 1 1
450-014 MSI Extra Pick
Retries
Set to 1 to allow a extra pick
retries MSI.
Range = 0 to 1 1
450-015 PFP Extra Pick
Retries
Set to 1 to allow a extra pick
retries PFP.
Range = 0 to 1 1
451-001 Sheets Until OC
Tray Full
Number of Sheets after OCT
sensor is met when tray full is
declared
Range = 0 to 100 50
Table 5 IOT NVM (IME) ID Range 460 to 470-xxx
NVM ID NVM Name NVM Description Settings Default
463-002 DrumTemp:
Paper prints
Temperature of drum when
printing on paper
Range = 0 to 2,000 555
463-003 DrumTemp:
Transparency
prints
Temperature of drum when
printing on transparency
Range = 0 to 2,000 555
463-004 DrumTemp: Low
power mode
Temperature of drum when
in low power mode
Range = 0 to 2,000 460
463-005 DrumTemp: Sleep
mode
Temperature of drum when
in sleep mode
Range = 0 to 2,000 0
464-001 Upper head stitch
factor
Upper head stitch factor The default is deliber-
ately out of range
Range = -
600,000,000 to
600,000,000
2,147,48
3,647
464-002 Upper left head
roll factor
Upper left head roll factor The default is deliber-
ately out of range
Range = -
400,000,000 to
400,000,000
2,147,48
3,647
Table 4 IOT NVM (IME) ID Range 440 to 459-xxx
NVM ID NVM Name NVM Description Settings Default
464-003 Upper right head
roll factor
Upper right head roll factor The default is deliber-
ately out of range
Range = -
400,000,000 to
400,000,000
2,147,48
3,647
464-004 Upper cross pro-
cess head offset
Upper cross process head
offset
Range = -
100,000,000 to
100,000,000
- 30,000
464-005 Lower head stitch
factor
Lower head stitch factor The default is deliber-
ately out of range
Range = -
600,000,000 to
600,000,000
2,147,48
3,647
464-006 Lower left head
roll factor
Lower left head roll factor The default is deliber-
ately out of range
Range = -
400,000,000 to
400,000,000
2,147,48
3,647
464-007 Lower right head
roll factor
Lower right head roll factor The default is deliber-
ately out of range
Range = -
400,000,000 to
400,000,000
2,147,48
3,647
464-008 Lower cross pro-
cess head offset
Lower cross process head
offset
Range = -
100,000,000 to
100,000,000
- 30,000
464-009 Head 1 process
stitch factor
Head 1 process stitch factor Range = -
600,000,000 to
600,000,000
0
464-010 Head 2 process
stitch factor
Head 2 process stitch factor Range = -
600,000,000 to
600,000,000
0
464-011 Head 3 process
stitch factor
Head 3 process stitch factor Range = -
600,000,000 to
600,000,000
0
464-012 Head 4 process
stitch factor
Head 4 process stitch factor Range = -
600,000,000 to
600,000,000
0
464-013 Purge needed
head 1
Purge needed head 1 Range = 0 to 1 1
464-014 Purge needed
head 2
Purge needed head 2 Range = 0 to 1 1
464-015 Purge needed
head 3
Purge needed head 3 Range = 0 to 1 1
464-016 Purge needed
head 4
Purge needed head 4 Range = 0 to 1 1
Table 5 IOT NVM (IME) ID Range 460 to 470-xxx
NVM ID NVM Name NVM Description Settings Default
