Xerox ColorQube 9301 Service Manual

February 2013
6-141
ColorQube® 9303 Family
dC131
General Procedures/Information
464-017 Upper SFWA
heads need flush
Upper SFWA heads need
flush
Range = 0 to 1 0
464-018 Lower SFWA
heads need flush
Lower SFWA heads need
flush
Range = 0 to 1 0
464-019 Amount of waste
ink in tray
Amount of waste ink in tray Range = 0 to
4,294,967,295
500,000
464-022 Xaxis Scaling:
Upper 2 heads
Cross-process movement
scale factor for mechanism
that holds upper two heads
Range = 35,535 to
85,535
65,850
464-023 Xaxis Scaling:
Lower 2 heads
Cross-process movement
scale factor for mechanism
that holds lower two heads
Range = 35,535 to
85,535
65,850
464-024 LPA Step Time Time delay to switch to sec-
ondary pump duty cycle
Range = 0 to
4,294,967,295
0
464-025 Initial LPA Duty Low pressure initial assist
pump duty cycle
Range = 0 to 255 60
464-026 Second LPA Duty Low pressure secondary
pump duty cycle
Range = 0 to 255 60
464-027 Single head
purge pre-wipe
LPA
The initial lpa pwm value for
the wipe when purging only
one head
Range = 0 to 255 0
464-028 Single head
purge post-wipe
LPA
The value of the lpa pwm
that is set after lpaStepTime
has expired when purging
only one head
Range = 0 to 255 0
465-001 Umbilical Upr
Temp: Printing
Temperature of upper
umbilical for printing
Range = 0 to 2,000 1,103
465-002 Umbilical Upr
Temp: Low Power
Temperature of upper
umbilical for low power
Range = 0 to 2,000 930
465-003 Umbilical Upr
Temp: Sleep
mode
Temperature of upper
umbilical for sleep mode
Range = 0 to 2,000 0
465-004 Umbilical Lwr
Temp: Printing
Temperature of lower umbil-
ical for printing
Range = 0 to 2,000 1,020
465-005 Umbilical Lwr
Temp: Low Power
Temperature of lower umbil-
ical for low power mode
Range = 0 to 2,000 930
465-006 Umbilical Lwr
Temp: Sleep
mode
Temperature of lower umbil-
ical for sleep mode
Range = 0 to 2,000 0
465-007 Melt Reservoir
Temp: Printing
Temperature of melt reser-
voir for printing
Range = 0 to 2,000 1,500
465-008 Melt Reservoir
Temp: Low Power
Temperature of melt reser-
voir for low power mode
Range = 0 to 2,000 930
Table 5 IOT NVM (IME) ID Range 460 to 470-xxx
NVM ID NVM Name NVM Description Settings Default
465-009 Melt Reservoir
Temp: Sleep
mode
Temperature of melt reser-
voir for sleep mode
Range = 0 to 2,000 0
465-010 Umb Upr Temp:
non-TEC Sleep
mode
Temperature of upper
umbilical for non-TEC sleep
mode.
Range = 0 to 2,000 0
465-011 Umb Lwr Temp:
non-TEC Sleep
mode
Temperature of lower umbil-
ical for non-TEC sleep
mode.
Range = 0 to 2,000 0
465-012 MeltRes Temp:
non-TEC Sleep
mode
Temperature of melt reser-
voir for non-TEC sleep
mode.
Range = 0 to 2,000 0
465-013 Umbilical Lwr
Temp: Pre-Ready
Temperature of lower umbil-
ical when in ink delivery on
demand pre-ready mode.
Range 0 to 2,000 930
465-014 Umbilical Upr
Temp: Pre-Ready
Temperature of upper
umbilical when in ink deliv
-
ery on demand pre-ready
mode.
Range 0 to 2,000 930
465-015 Melt Reservoir
Temp: Pre-Ready
Temperature of melt reser-
voir when in ink delivery on
demand pre-ready mode.
Range 0 to 2,000 930
465-016 TIDO threshold
time for K
TIDO threshold time
remaining at which the ink
delivery system starts war
-
mup for black ink.
Range 0 to 65,535 120
465-017 TIDO threshold
time for CMY
TIDO threshold time
remaining at which the ink
delivery system starts war
-
mup for CMY ink.
Range 0 to 65,535 300
465-018 TIDO threshold
mass for K
TIDO threshold mass
remaining at which the ink
delivery system starts war
-
mup for black ink.
Range 0 to 65,535 125
465-019 TIDO threshold
mass for CMY
TIDO threshold mass
remaining at which the ink
delivery system starts war
-
mup for CMT ink.
Range 0 to 65,535 125
465-020 TIDO time after
print job
TIDO time to wait after print
job completes before cool
-
ing the ink delivery system
to its pre-ready state.
Range 0 to 65,535 0
Table 5 IOT NVM (IME) ID Range 460 to 470-xxx
NVM ID NVM Name NVM Description Settings Default
