ColorQube® 9303 Family
OF 4b
Status Indicator RAPs
Paper feeder com-
munication fault.
Call for assistance.
92-535-00 IME communications
problem with paper
feeder platform. High
capacity paper tray
not available
Switch the machine off then on, GP
14. Check connection to printer. If
problem persists, perform the 75-
312-00 IME to Tray 5 Communica
-
tion Failure RAP. Copying and print-
ing are not available
Paper jam in area
1A
82-100-00 IME jam at zone 1A
(middle vertical) (tray
5 not installed)
Open middle left door, clear the
paper jam. If the problem persists,
perform the 82-110-00 to 82-114-00,
82-152-00, 82-157-00 to 82-159-00,
82-164-00 to 82-166-00 RAP and
82-133-00 RAP. Copying and print
-
ing are not available
Paper jam in area
1A
82-100-01 IME jam at zone 1A
(middle vertical) (A 4
PFP installed)
Slide tray 5 away from the machine,
open the middle left door, clear the
paper jam. If the problem persists,
perform the 82-110-00 to 82-114-00,
82-152-00, 82-157-00 to 82-159-00,
82-164-00 to 82-166-00 RAP. Copy
-
ing and printing are not available
Paper jam in Area
1a
82-100-02 Jam at Zone 1A (mid-
dle vertical) (A4 PFP
installed)
Slide Tray 5 away from the machine,
open the middle left door, clear the
paper jam. If the problem persists,
perform the 82-110-00 to 82-114-00,
82-152-00, 82-157-00 to 82-159-00,
82-164-00 to 82-166-00 RAP
Paper jam in area
2
82-101-00 IME jam at zone 2
(upper vertical)
Open upper left door, clear the paper
jam. Refer to 82-125-00 to 82-133-
00, 82-153-00, 82-160-00, 82-162-
00, 82-163-00 RAP, 82-132-00, 82-
155-00. Copying and printing are not
available
Paper jam in area
3a
01-108-00 IME jam at zone 3a
(registration / pre
-
heat), open front door.
Clear the paper jam in area 3a. Print
and copy services are disabled.
Refer to 89-110-00 to 89-113-00, 89-
129-00 RAP, 89-125-00 to 89-128-
00, 89-130-00, 89-131-00 RAP
Paper jam in area
3a and 4a.
01-110-00 IME jam at zone 3a
(registration) and 4a
(exit), open front door
Clear the paper jam in area 3a and
4a. Print and copy services are dis
-
abled.
Refer to 89-110-00 to 89-113-00, 89-
129-00 RAP, 89-125-00 to 89-128-
00, 89-130-00, 89-131-00 RAP, 89-
110-00 to 89-113-00, 89-129-00 RAP
Table 3 Status messages O to R
UI Message
Status
Code Reason for Message Reference / Action
Paper jam in area
3b and 4b.
01-105-00 IME jam at zone 3b
(post transfix) and 4b
(horizontal), open
front door.
Clear the paper jam in area 3b and
4b. Print and copy services are dis
-
abled.
Paper jam in area
3b.
01-104-00 IME jam at zone 3b
(post transfix), open
front door
Clear the paper jam in area 3b. Print
and copy services are disabled.
Paper jam in area
4a.
01-102-00 IME jam at zone 4a
(exit), open front door.
Clear the paper jam in area 4a. Print
and copy services are disabled.
Refer to 10-110-00 to 10-113-00, 10-
125-00 to 10-128-00, 10-147-00, 10-
148-00 RAP, 10-140-00 to 10-146-
00, 10-149-00 to 10-151-00 RAP, 83-
110-00, 83-111-00, 83-113-00, 83-
114-00, 83-118-00 RAP, 83-112-00,
83-115-00, 83-116-00, 83-117-00,
83-119-00 RAP
Paper jam in area
4b.
01-101-00 IME jam at zone 4b
(horizontal), open
front door.
Clear the paper jam in area 4b. Print
and copy services are disabled.
Refer to 82-145-00, 82-146-00, 82-
150-00, 82-151-00, 82-156-00 RAP,
82-141-00, 82-147-00, 82-148-00,
82-154-00 RAP, 89-110-00 to 89-
113-00, 89-129-00 RAP
Paper jam in areas
3a and 3b.
01-112-00 IME jam at zone 3a
(registration) and 3b
(post transfix), open
front door.
Clear the paper jam in area 3a and
3b. Print and copy services are dis
-
abled.
Refer to 10-110-00 to 10-113-00, 10-
125-00 to 10-128-00, 10-147-00, 10-
148-00 RAP, 10-140-00 to 10-146-
00, 10-149-00 to 10-151-00 RAP, 83-
110-00, 83-111-00, 83-113-00, 83-
114-00, 83-118-00 RAP, 83-112-00,
83-115-00, 83-116-00, 83-117-00,
83-119-00 RAP
Paper jam in areas
3a and 4b.
01-109-00 IME jam at zone 3a
(registration) and 4b
(horizontal), open
front door
Clear the paper jam in area 3a and
4b. Print and copy services are dis
-
abled.
Refer to 10-110-00 to 10-113-00, 10-
125-00 to 10-128-00, 10-147-00, 10-
148-00 RAP, 10-140-00 to 10-146-
00, 10-149-00 to 10-151-00 RAP, 83-
110-00, 83-111-00, 83-113-00, 83-
114-00, 83-118-00 RAP, 83-112-00,
83-115-00, 83-116-00, 83-117-00,
83-119-00 RAP
Table 3 Status messages O to R
UI Message
Status
Code Reason for Message Reference / Action
