ColorQube® 9303 Family
OF 4b
Status Indicator RAPs
Paper jam in areas
3a, 3b and 4a
01-114-00 IME jam at zone 3a
(registration), 3b (post
transfix) and 4a (exit),
open front door
Clear the paper jam in area 3a, 3b
and 4a. Print and copy services are
disabled.
Refer to 10-110-00 to 10-113-00, 10-
125-00 to 10-128-00, 10-147-00, 10-
148-00 RAP, 10-140-00 to 10-146-
00, 10-149-00 to 10-151-00 RAP, 83-
110-00, 83-111-00, 83-113-00, 83-
114-00, 83-118-00 RAP, 83-112-00,
83-115-00, 83-116-00, 83-117-00,
83-119-00 RAP
Paper jam in areas
3a, 3b and 4b
01-113-00 IME jam at zone 3a
(registration), 3b (post
transfix) and 4b (hori
-
zontal), open front
door
Clear the paper jam in area 3a, 3b
and 4b. Print and copy services are
disabled.
Refer to 10-110-00 to 10-113-00, 10-
125-00 to 10-128-00, 10-147-00, 10-
148-00 RAP, 10-140-00 to 10-146-
00, 10-149-00 to 10-151-00 RAP, 83-
110-00, 83-111-00, 83-113-00, 83-
114-00, 83-118-00 RAP, 83-112-00,
83-115-00, 83-116-00, 83-117-00,
83-119-00 RAP
Paper jam in areas
3a, 3b, 4a and 4b.
01-115-00 IME jam at zone 3a
(registration), 3b (post
transfix), 4a (exit) and
4b (horizontal), open
front door
Clear the paper jam in area 3a, 3b,
4a and 4b. Print and copy services
are disabled.
Refer to 10-110-00 to 10-113-00, 10-
125-00 to 10-128-00, 10-147-00, 10-
148-00 RAP, 10-140-00 to 10-146-
00, 10-149-00 to 10-151-00 RAP, 83-
110-00, 83-111-00, 83-113-00, 83-
114-00, 83-118-00 RAP, 83-112-00,
83-115-00, 83-116-00, 83-117-00,
83-119-00 RAP
Paper jam in areas
3a, 4a and 4b.
01-111-00 IME jam at zone 3a
(registration), 4a (exit)
and 4b (horizontal),
open front door
Clear the paper jam in area 3a, 4a
and 4b. Print and copy services are
disabled.
Refer to 10-110-00 to 10-113-00, 10-
125-00 to 10-128-00, 10-147-00, 10-
148-00 RAP, 10-140-00 to 10-146-
00, 10-149-00 to 10-151-00 RAP, 83-
110-00, 83-111-00, 83-113-00, 83-
114-00, 83-118-00 RAP, 83-112-00,
83-115-00, 83-116-00, 83-117-00,
83-119-00 RAP
Table 3 Status messages O to R
UI Message
Status
Code Reason for Message Reference / Action
Paper jam in areas
3b and 4a.
01-106-00 IME jam at zone 3b
(post transfix) and 4a
(exit), open front door.
Clear the paper jam in area 3b and
4a. Print and copy services are dis
-
abled.
Refer to 10-110-00 to 10-113-00, 10-
125-00 to 10-128-00, 10-147-00, 10-
148-00 RAP, 10-140-00 to 10-146-
00, 10-149-00 to 10-151-00 RAP, 83-
110-00, 83-111-00, 83-113-00, 83-
114-00, 83-118-00 RAP, 83-112-00,
83-115-00, 83-116-00, 83-117-00,
83-119-00 RAP
Paper jam in areas
3b, 4a and 4b.
01-107-00 IME jam at zone 3b
(post transfix), 4a
(exit) and 4b (horizon
-
tal), open front door.
Clear the paper jam in area 3b, 4a
and 4b. Print and copy services are
disabled.
Refer to 10-110-00 to 10-113-00, 10-
125-00 to 10-128-00, 10-147-00, 10-
148-00 RAP, 10-140-00 to 10-146-
00, 10-149-00 to 10-151-00 RAP, 83-
110-00, 83-111-00, 83-113-00, 83-
114-00, 83-118-00 RAP, 83-112-00,
83-115-00, 83-116-00, 83-117-00,
83-119-00 RAP
Paper jam in areas
4a and 4b.
01-103-00 IME jam at zone 4a
(exit) and 4b (horizon
-
tal), open front door.
Clear the paper jam in area 4a and
4b. Print and copy services are dis
-
abled.
Refer to 10-110-00 to 10-113-00, 10-
125-00 to 10-128-00, 10-147-00, 10-
148-00 RAP, 10-140-00 to 10-146-
00, 10-149-00 to 10-151-00 RAP, 83-
110-00, 83-111-00, 83-113-00, 83-
114-00, 83-118-00 RAP, 83-112-00,
83-115-00, 83-116-00, 83-117-00,
83-119-00 RAP
Paper jam in fin-
isher folder unit.
12-718-00 Sheet over tri-folder
assist sensor
Clear the paper jam.
If the problem persists, perform the
12-185-00-171 to 12-187-00-171
RAP
Paper jam in fin-
isher folder unit.
12-719-00 Sheet over tri-folder
exit sensor
Clear the paper jam.
If the problem persists, perform the
12-185-00-171 to 12-187-00-171
RAP
Paper jam in the
document feeder
05-520-00 Post feed and take-
away roll jam
Remove the sheet. If the problem
persists, perform the 05-330-00, 05-
331-00 Feed Sensor Failure RAP
Table 3 Status messages O to R
UI Message
Status
Code Reason for Message Reference / Action
