Xerox ColorQube 9301 - Page 618

February 2013
2-594
ColorQube® 9303 Family
OF 4b
Status Indicator RAPs
Ready to scan.
Copying and print
-
ing not available.
Jam in area 1b.
70-111-01 Jam in the lower
feeder vertical trans
-
port (A4 tray 5
installed)
Clear the media jam. Copying and
printing are not available. If the prob
-
lem persists, perform the 71-101-00
to 71-161-00 RAP, 72-101-00 to 72-
161-00 RAP
Ready to scan.
Copying and print
-
ing not available.
Jam in area 1b.
70-111-02 Jam in the lower
feeder vertical trans
-
port (A3 tray 5
installed)
Clear the media jam. Copying and
printing are not available. If the prob
-
lem persists, perform the 71-101-00
to 71-161-00 RAP, 72-101-00 to 72-
161-00 RAP
Ready to scan.
Copying and print
-
ing not available.
Jam in paper trans
-
port.
73-111-00 Jam in the tray 3 hori-
zontal transport
Clear the media jam. Copying and
printing are not available. If the prob
-
lem persists, perform the 73-101-00
to 73-161-00 Tray 3 Mis-Feed Jam
RAP
Ready to scan.
Copying and print
-
ing not available.
Misfeed in tray 1
71-102-00 Misfeed in tray 1 Clear the media jam. Copying and
printing are not available. If the prob
-
lem persists, perform the 71-101-00
to 71-161-00 RAP
Ready to scan.
Copying and print
-
ing not available.
Misfeed in tray 2
72-102-00 Misfeed in tray 2 Clear the media jam. Copying and
printing are not available.
Refer to 72-101-00 to 72-161-00
RAP
Ready to scan.
Copying and print
-
ing not available.
Misfeed in tray 3
73-102-00 Misfeed in tray 3 Clear the media jam. Copying and
printing are not available.
Refer to 73-101-00 to 73-161-00
RAP
Ready to scan.
Copying and print
-
ing not available.
Paper transport is
open.
73-305-00 the feeder horizontal
transport drawer is
open
Close the feeder horizontal transport.
Copying and printing are not avail
-
able. If the problem persists, perform
the 73-325-00 Feeder HT Drawer
Open in Run RAP
Registration in
progress
89-560-00 IME registration is
being calibrated
Please wait. The printer is tempo-
rarily unavailable
Reload sheets in
document feeder.
05-527-00 There is a document
in the DADH at power
on or exit from power
save
Remove the sheets from the Original
Input Tray.
Remove docu-
ments from the
document feeder
input tray or close
the document
feeder
22-505-00 Documents are
sensed in the DADH
tray during IIT standby
and document han
-
dler cover is open
To scan from the document glass,
remove documents in the document
feeder input tray. To use the docu
-
ment feeder to scan your documents,
lower the document feeder
Table 3 Status messages O to R
UI Message
Status
Code Reason for Message Reference / Action
Remove docu-
ments from the
document feeder
input tray or close
the document
feeder
22-505-02 Documents are
sensed in the DADH
tray during IIT standby
and document han
-
dler cover is open
To scan from the document glass,
remove documents in the document
feeder input tray. To use the docu
-
ment feeder to scan your documents,
lower the document feeder
Remove the docu-
ment. It is too short
to be fed by Docu
-
ment Feeder
05-560-00 Upon fault 05-310
being raised
Remove document from DADH dur-
ing jam clearance, If the problem
persists, perform the 05-310-00 RAP
Re-order docu-
ment feeder - feed
roller but DO NOT
replace until
prompted
05-578-00 DADH roller feeds
reaches near end of
life
Order new DADH feed roll assembly,
PL 5.15 Item 1.
Re-order docu-
ment feeder - feed
roller but DO NOT
replace until
prompted
05-547-00 DADH feed roll
assembly near end of
life
Re-order feed roll assembly PL 5.15
Item 1.
Re-order Xerox
ColorQube Ink
93-821-00 Black ink reorder
threshold has been
reached
Load more black solid ink. Copying
and printing can continue. If the ink
stick cannot be loaded, go to OF 11
Re-order Xerox
ColorQube Ink
93-822-00 Magenta ink reorder
threshold has been
reached
Load more magenta solid ink. Copy-
ing and printing can continue. If the
ink stick cannot be loaded, go to OF
11
Re-order Xerox
ColorQube Ink
93-823-00 Cyan ink reorder
threshold has been
reached
Load more cyan solid ink. Copying
and printing can continue. If the ink
stick cannot be loaded, go to OF 11
Re-order Xerox
ColorQube Ink
93-824-00 Yellow ink reorder
threshold has been
reached
Load more yellow solid ink. Copying
and printing can continue. If the ink
stick cannot be loaded, go to OF 11
Replace the Docu-
ment Feed Roller.
05-579-00 DADH roller feeds
reaches end of life
Install new DADH feed roll assembly,
PL 5.15 Item 1.
Table 4 Status messages S to Y
UI Message
Status
Code
Reason for Message Reference / Action
Scan and copy services
not available. Print ser
-
vice is available
05-570-00 DADH jam. Remove, then re-load all doc-
ument in the DADH.
Table 3 Status messages O to R
UI Message
Status
Code Reason for Message Reference / Action
