Xerox ColorQube 9301 - Page 624

February 2013
2-600
ColorQube® 9303 Family
OF 4b
Status Indicator RAPs
Tray 1 is open 71-301-00 the dedicated tray 1 is
open
Check the paper and close
the tray. Printing can con
-
tinue from other trays.
Refer to WD 7.5
Tray 1 is open 71-302-00 the adjustable tray 1 is
open
Check the paper and close
the tray. Printing can con
-
tinue from other trays.
Refer to WD 7.5
Tray 1 lifting 71-536-00 Tray 1 lifting No service action required.
Print and copy services can
continue from other rays if
the correct media is available
Tray 2 guides are not set
properly
01-545-02 The dedicated tray 2 is
closed with media size
other than what was set
Reload required paper and
correctly adjust the paper
guides
Tray 2 is empty. Add
paper
72-530-00 Tray 2 is out of media Add media. Print and copy
services can continue from
other trays if the correct
media is available. Refer to
72A RAP
Tray 2 is nearly empty.
Add paper
72-535-00 Tray 2 media low Add media. Print and copy
services can continue from
other trays if the correct
media is available
Tray 2 is not available.
Notify your system
administrator
72-313-00 Tray 2 out of service
(mechanical failure)
Switch the machine off then
on, GP 14. Print and copy
services can continue from
other trays if the correct
media is available. If the
problem persists, perform the
72-215-00 Tray 2 Elevate Up
Failure RAP
Tray 2 is open 72-302-00 The adjustable tray 2 is
open
Close Tray. Print and copy
services can continue from
other rays if the correct
media is available.
Refer to 72-320-00 RAP and
WD 7.5
Tray 2 is open. Check
paper and close tray
72-301-00 The dedicated tray 2 is
open
Close tray. Print and copy
services can continue from
other rays if the correct
media is available. Refer to
72-320-00 RAP and WD 7.5
Table 4 Status messages S to Y
UI Message
Status
Code Reason for Message Reference / Action
Tray 2 lifting 72-536-00 Tray 2 lifting No service action required.
Print and copy services can
continue from other trays if
the correct media is available
Tray 3 is empty. Add
paper
73-530-00 Tray 3 is out of media Add media. Print and copy
services can continue from
other trays if the correct
media is available.
If the problem persists, per-
form the 73A RAP
Tray 3 is lifting 73-536-00 Tray 3 lifting Print and copy services can
continue from other trays if
the correct media is available
Tray 3 is nearly empty.
Add paper
73-535-00 Tray 3 media low Add media. Print and copy
services can continue from
other trays if the correct
media is available
Tray 3 is not available.
Notify your system
administrator
73-313-00 Tray 3 out of service
(mechanical failure)
Switch the machine off then
on, GP 14. Print and copy
services can continue from
other trays if the correct
media is available. If the
problem persists, perform the
73-212-00 RAP, 73-215-00
RAP
Tray 3 is open 73-301-00 Tray 3 is open Close Tray. Printing can con-
tinue from other trays. If the
problem persists, perform the
73-320-00 RAP
Tray 3 is open. Check
paper and close the tray
73-300-00 The dedicated tray 3 is
open
Close Tray. Print and copy
services can continue from
other trays if the correct
media is available
Tray 3 is open. Check
paper and close the tray
73-302-00 The adjustable tray 3 is
open
Close Tray. Print and copy
services can continue from
other trays if the correct
media is available. If the
problem persists, perform the
73-320-00 RAP
Table 4 Status messages S to Y
UI Message
Status
Code Reason for Message Reference / Action
