ColorQube® 9303 Family
OF 12
Status Indicator RAPs
NOTE: A number other than 0 indicates a fault.
Table 1 Service code table
Service
Code
Drum
Drive
Belt
Error
PEST
Warning
Exist
IOD
Chronic
Jets
Detected
IOD Y Run
out
NVRAM
Reset
IOD in
Degraded
Mode
Reg /
Preheat
Calibrated
Required
Transfix
Calibration
NVRAM
Reset
0 0 0 0 0 0 0 0
1 0 0 0 0 0 0 1
2 0 0 0 0 0 1 0
3 0 0 0 0 0 1 1
4 0 0 0 0 1 0 0
5 0 0 0 0 1 0 1
6 0 0 0 0 1 1 0
7 0 0 0 0 1 1 1
8 0 0 0 1 0 0 0
9 0 0 0 1 0 0 1
10 0 0 0 1 0 1 0
11 0 0 0 1 0 1 1
12 0 0 0 1 1 0 0
13 0 0 0 1 1 0 1
14 0 0 0 1 1 1 0
15 0 0 0 1 1 1 1
16 0 0 1 0 0 0 0
17 0 0 1 0 0 0 1
18 0 0 1 0 0 1 0
19 0 0 1 0 0 1 1
20 0 0 1 0 1 0 0
21 0 0 1 0 1 0 1
22 0 0 1 0 1 1 0
23 0 0 1 0 1 1 1
24 0 0 1 1 0 0 0
25 0 0 1 1 0 0 1
26 0 0 1 1 0 1 0
27 0 0 1 1 0 1 1
28 0 0 1 1 1 0 0
29 0 0 1 1 1 0 1
30 0 0 1 1 1 1 0
31 0 0 1 1 1 1 1
32 0 1 0 0 0 0 0
33 0 1 0 0 0 0 1
34 0 1 0 0 0 1 0
35 0 1 0 0 0 1 1
36 0 1 0 0 1 0 0
37 0 1 0 0 1 0 1
38 0 1 0 0 1 1 0
39 0 1 0 0 1 1 1
40 0 1 0 1 0 0 0
41 0 1 0 1 0 0 1
42 0 1 0 1 0 1 0
43 0 1 0 1 0 1 1
44 0 1 0 1 1 0 0
45 0 1 0 1 1 0 1
46 0 1 0 1 1 1 0
47 0 1 0 1 1 1 1
48 0 1 1 0 0 0 0
49 0 1 1 0 0 0 1
50 0 1 1 0 0 1 0
51 0 1 1 0 0 1 1
52 0 1 1 0 1 0 0
53 0 1 1 0 1 0 1
54 0 1 1 0 1 1 0
55 0 1 1 0 1 1 1
56 0 1 1 1 0 0 0
57 0 1 1 1 0 0 1
58 0 1 1 1 0 1 0
59 0 1 1 1 0 1 1
60 0 1 1 1 1 0 0
61 0 1 1 1 1 0 1
62 0 1 1 1 1 1 0
63 0 1 1 1 1 1 1
64 1 0 0 0 0 0 0
65 1 0 0 0 0 0 1
66 1 0 0 0 0 1 0
67 1 0 0 0 0 1 1
68 1 0 0 0 1 0 0
69 1 0 0 0 1 0 1
70 1 0 0 0 1 1 0
71 1 0 0 0 1 1 1
72 1 0 0 1 0 0 0
Table 1 Service code table
Service
Code
Drum
Drive
Belt
Error
PEST
Warning
Exist
IOD
Chronic
Jets
Detected
IOD Y Run
out
NVRAM
Reset
IOD in
Degraded
Mode
Reg /
Preheat
Calibrated
Required
Transfix
Calibration
NVRAM
Reset
