Xerox ColorQube 9301

February 2013
2-613
ColorQube® 9303 Family
OF 12
Status Indicator RAPs
73 1 0 0 1 0 0 1
74 1 0 0 1 0 1 0
75 1 0 0 1 0 1 1
76 1 0 0 1 1 0 0
77 1 0 0 1 1 0 1
78 1 0 0 1 1 1 0
79 1 0 0 1 1 1 1
80 1 0 1 0 0 0 0
81 1 0 1 0 0 0 1
82 1 0 1 0 0 1 0
83 1 0 1 0 0 1 1
84 1 0 1 0 1 0 0
85 1 0 1 0 1 0 1
86 1 0 1 0 1 1 0
87 1 0 1 0 1 1 1
88 1 0 1 1 0 0 0
89 1 0 1 1 0 0 1
90 1 0 1 1 0 1 0
91 1 0 1 1 0 1 1
92 1 0 1 1 1 0 0
93 1 0 1 1 1 0 1
94 1 0 1 1 1 1 0
95 1 0 1 1 1 1 1
96 1 1 0 0 0 0 0
97 1 1 0 0 0 0 1
98 1 1 0 0 0 1 0
99 1 1 0 0 0 1 1
100 1 1 0 0 1 0 0
101 1 1 0 0 1 0 1
102 1 1 0 0 1 1 0
103 1 1 0 0 1 1 1
104 1 1 0 1 0 0 0
105 1 1 0 1 0 0 1
106 1 1 0 1 0 1 0
107 1 1 0 1 0 1 1
108 1 1 0 1 1 0 0
109 1 1 0 1 1 0 1
110 1 1 0 1 1 1 0
Table 1 Service code table
Service
Code
Drum
Drive
Belt
Error
PEST
Warning
Exist
IOD
Chronic
Jets
Detected
IOD Y Run
out
NVRAM
Reset
IOD in
Degraded
Mode
Reg /
Preheat
Calibrated
Required
Transfix
Calibration
NVRAM
Reset
111 1 1 0 1 1 1 1
112 1 1 1 0 0 0 0
113 1 1 1 0 0 0 1
114 1 1 1 0 0 1 0
115 1 1 1 0 0 1 1
116 1 1 1 0 1 0 0
117 1 1 1 0 1 0 1
118 1 1 1 0 1 1 0
119 1 1 1 0 1 1 1
120 1 1 1 1 0 0 0
121 1 1 1 1 0 0 1
122 1 1 1 1 0 1 0
123 1 1 1 1 0 1 1
124 1 1 1 1 1 0 0
125 1 1 1 1 1 0 1
126 1 1 1 1 1 1 0
127 1 1 1 1 1 1 1
Table 2 Service Actions
Fault Description Actions Required
Drum drive belt error Drum drive belt is worn or dam-
aged.
Go to 94-547-00, 94-555-00 Y-axis
Belt Ratio Error RAP
PEST Warnings
Exist
Check dC123 PEST Fault His-
tory for PEST chain link errors.
Go to the appropriate RAP
Chronic jets detected Chronic jets are detected on
one or more printheads.
Go to 91-638-00 IOD Detects
Chronic Jet Error RAP
Y run out NVM reset The NVRAM has been cor-
rupted and was reset to
default.or dC301 with Domain =
Copier, NVM Data = System or
All, was done resetting the
NVRAM
Perform dC977 Drum Run out Cali-
bration.
IOD in degraded
mode
Print quality is suboptimal. Go to 91-636-00 IOD in Degraded
Mode RAP. If the fault remains,
check the stitch adjust and roll
adjust motor lead screws, PL 91.20
Item 21 and PL 91.25 Item 21 for
cracks. Install new components as
necessary.
Table 1 Service code table
Service
Code
Drum
Drive
Belt
Error
PEST
Warning
Exist
IOD
Chronic
Jets
Detected
IOD Y Run
out
NVRAM
Reset
IOD in
Degraded
Mode
Reg /
Preheat
Calibrated
Required
Transfix
Calibration
NVRAM
Reset
