February 2013
4-160
ColorQube® 9303 Family
REP 12.28-171
Repairs/Adjustments
10. Figure 2, lower the stapler bracket.
Figure 2 Lowering stapler bracket
1
Release the rear follower
from the slot using a
screwdriver.
2
Pull the stapler bracket
handle to open the staplers
fully.
