Xerox WorkCentre 3550 Service Manual

April 2010
6-18
Phaser 3635MFP/WorkCentre 3550
GP 9
General Procedures/Information
GP 9 Paper and Media Specifications
Purpose
To list the paper and media size specifications.
Procedure
Refer to the following specifications:
• Paper Specifications
• Transparency Specification
• Envelope Specification
• Label Specification
Paper Specifications
NOTE: Ensure that the paper tray settings match the paper size in the tray.
Refer to Table 1 for the paper and media sizes that can be used in the machine. Refer to Table
2 for the paper or media weight that can be used in the machine.
NOTE: 1. COM-10 envelope weight must not exceed 75 gsm (20lb).
NOTE: 2. Paper weight must be 60 gsm - 120 gsm (16lb - 32lb bond).
NOTE: 3. Long grain paper only.
Transparency Specification
Refer to Table 3 for the transparency sizes that can be used in the machine.
NOTE: Must be standard Xerox transparencies.
Envelope Specification
Refer to Table 4 for the envelope sizes that can be used in the machine.
Label Specification
Refer to Table 5 for the label sizes that can be used in the machine.
Table 1 Paper and media specifications
Paper Type Mode
Size Input Source
W x L (mm) W x L (inch) Bypass Trays Duplex
Letter Print/Copy/Fax 215.9 x 279 8.5 x 11 X X X
Legal Print/Copy/Fax 215.9 x 355.6 8.5 x 14 X X X
Folio Print/Copy/Fax 216 x 330 8.5 x 13 X X X
Oficio Print/Copy/Fax 216 x 343 8.5 x 13.5 X X X
A4 Print/Copy/Fax 210 x 297 8.27 x 11.69 X X X
JIS B5 Print 182 x 257 7.17 x 10.12 X X (see
NOTE 2)
X
Executive Print 184.2 x 266.7 7.25 x 10.5 X X (see
NOTE 2)
X
A5 Print/Copy 148.5 x 210 5.85 x 8.27 X X (see
NOTE 2)
X (see
NOTE 3)
Statement Print/Copy N/A 5.5 x 8.5 X X (see
NOTE 2)
X (see
NOTE 3)
A6 CARD Print 105 x 148.5 4.13 x 5.85 X
Post card 4 x 6 Print 101.6 x 152.4 4 x 6 X
Hagaki Print 100 x 148 3.94 x 5.83 X
Envelope B5 Print 176 x 250 N/A X X (see
NOTE 2)
Envelope 7-3/4 Print 98.4 x 190.5 3.88 x 7.5 X X (see
NOTE 2)
Envelope
COM-10 (see
NOTE 1)
Print 105 x 241 4.12 x 9.5 X X (see
NOTE 2)
Envelope DL Print 110 x 220 4.33 x 8.66 X X (see
NOTE 2)
Envelope C5 Print 162 x 229 6.38 x 9.02 X X (see
NOTE 2)
Envelope C6 Print 114 x 162 N/A X X (see
NOTE 2)
Custom Print 98 x 148 -
215.9 x 355.6
3.86 x 5.83 -
8.5 x 14
X X (see
NOTE 2)
Table 2 Paper or media weights
Paper or Media Source Weight
Tray 1 60 - 90 gsm (16 - 24lb bond)
Tray 2 60 - 90 gsm (16 - 24lb bond)
Bypass 60 - 163 gsm (16 - 40lb bond)
Duplex 60 - 75gsm (16 - 20lb bond)
Table 3 Transparency specifications
Size Weight Curl Shearing Angle
A4 or Letter (see NOTE) 138 - 146 gsm (37 - 39lb) +/- 5mm +/- 4 degrees
Table 4 Envelope specifications
Length Width Weight Curl Twist
162 x 250 mm
(6.3 x 9.8 inches)
98.4 x 176 mm
(3.9 x 6.9 inches)
75 - 90 gsm
(20 - 24lb)
Less than 2mm Less than 6mm
Table 5 Label specifications
Size Type Weight
A4 or Letter Paper 120 - 150 gsm (32 - 40lb)
Table 1 Paper and media specifications
Paper Type Mode
Size Input Source
W x L (mm) W x L (inch) Bypass Trays Duplex

Xerox WorkCentre 3550 Specifications

General

Print technology	-
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Duplex printing mode	Auto
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Paper input type	Paper tray
Total input capacity	550 sheets
Total output capacity	250 sheets
Total number of input trays	1
Maximum number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	60 sheets
Custom media width	148 - 210 mm
Custom media length	216 - 356 mm
Paper tray media types	Heavy paper, Lightweight paper, Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 43 lbs
Auto Document Feeder (ADF) media weight (imperial)	12 - 28 lbs
Internal memory	256 MB
Maximum internal memory	512 MB
Sound power level (standby)	39 dB
Sound pressure level (printing)	55 dB
Maximum duty cycle	75000 pages per month
Page description languages	PCL 5e, PCL 6, PostScript 3
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi	No
Security algorithms	802.1x RADIUS
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional x64
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	10 s
Faxing	Mono faxing
Fax memory	7 MB
Modem speed	33.6 Kbit/s
Fax forwarding to	E-mail, FTP, Fax, PC, SMB
Fax coding methods	JBIG, JPEG, MH, MMR (Fax coding method), MR
Product color	Blue, Grey
Market positioning	Business
Scan to	E-mail, FTP, OCR, PC, SMB, USB
Scanner type	ADF scanner
Maximum scan area	216 x 356 mm
Scan speed (black)	26 ppm
Scan speed (color)	8 ppm
Image formats supported	JPG
Document formats supported	PDF
Optical scanning resolution	300 x 300 DPI
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	60 W
Power consumption (printing)	600 W
Power consumption (PowerSave)	20 W
Power consumption (average operating)	- W
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
Package depth	619 mm
Package width	676 mm
Package height	696 mm
Package weight	29700 g
Certification	UL, CE, FCC

Weight and Dimensions

Depth	488 mm
Width	582 mm
Height	553 mm
