April 2010
6-41
Phaser 3635MFP/WorkCentre 3550
dC132, dC305
General Procedures/Information
• Fax Job NVM
• Fax Configuration NVM
• Fax SA/KO Settings NVM
5. Switch off the machine, then switch on the machine.
NVM Initialization - Fax Procedure (3550)
1. Enter diagnostics, GP 1 Diagnostics Entry.
2. Select Fax Diagnostics and press the OK key.
3. Select DC132 NVM Initialization - Fax and press the OK key.
4. Select Yes and press the OK key to confirm initialization of the NVM values. All Fax NVM
will be reset.
dC305 UI Test
Purpose
To initiate component testing of the local UI. This function also provides a means to test the UI
memory and to restart the local UI.
Description
Refer to GP 12 User Interface Tests Description.
Procedure
Go to the relevant procedure:
• 3635
• 3550
3635
1. Enter diagnostics, GP 1 Diagnostics Entry.
2. Select, Diagnostics Routines, Copier Routines, dC305 UI Tests.
3. Touch the appropriate test button.
4. Touch Start Test and follow the on-screen instructions.
3550
1. Enter diagnostics, GP 1 Diagnostics Entry.
2. Select dC305 UI Tests.
3. Select the complete panel or reduced panel test.
4. Press the OK key and follow the on-screen instructions.
Table 2 Fax NVM
Fax file type Category Kill All
All Fax
Directories
Fax
Job
NVM
Fax
Configuration
NVM
Fax SA/KO
Settings
NVM
Dial Directories Y Y
Group Directories Y Y
Junk Directories Y Y
Logo Directories Y Y
Mailbox Directories Y Y
Poll Directories Y Y
Job Sets Y Y
Jobs Y Y
Image Y Y
Bitmaps Y Y
Job ID Y Y
Mailbox Y Y
Alarm Y Y
Fax Protocol Trace Y Y
Protocol Records Y Y
Container Versions Y
FAX NVM Configuration Y
Fax NVM SA/KO Settings Y
