Phaser 3635MFP/WorkCentre 3550
IQ1
Image Quality
IQ1 Image Quality Entry RAP
Use this RAP to determine the source of an image quality problem.
Initial Actions
• Check the condition of the paper. Do not use incorrectly cut paper, damp paper, paper
with rough edges, badly drilled paper, paper with wrapper wax or glue. Paper and media
should be stored flat, enclosed in wrappers, in a cool dry environment. If necessary, load
new paper in the trays.
• Ensure that the paper tray settings match the paper or media size in the trays.
• Ensure that the media is within specifications. Refer to GP 9 Paper and Media Specifica-
tions.
• Check that paper tray guides are set to the correct paper size.
• Check the document guides on the DADF.
• Check the original documents for defects.
• Ensure that the image adjustment mode selections are those used by the customer.
• Check that the machine fans are working, go to the OF3 Air Systems RAP.
Procedure
If necessary, refer to IQ1 Internal Test Patterns for:
• A description of image quality defects.
• The optimum test pattern to be used to diagnose the defect.
• An example of all internal test patterns.
If possible, use the customer job to recreate the image quality problem.
Enter dC606 Internal Print Test Patterns (3635 Only). Select a suitable test pattern. Select the
Features, 1 or 2 sided and paper size. Press Start Test. Go to the relevant RAP:
• IQ2 Blank Copies RAP
• IQ3 Black Copies or Prints RAP
• IQ4 Blurred Image From the Scanner RAP
• IQ5 Vertical Black Lines or Bands RAP
• IQ6 Vertical White Lines RAP
• IQ7 Light Image RAP
• IQ8 Dark Image RAP
• IQ9 Background RAP
• IQ10 Ghost Images RAP
• IQ11 Marks on Back of Paper RAP
• IQ12 Poor Fusing RAP
• IQ13 Partial Blank Image (Not Periodic) RAP
• IQ14 Partial Blank Image (Periodic) RAP
• IQ15 Different Image Density (Left and Right) RAP
• IQ16 Horizontal Bands RAP
• IQ17 Repeated Printing Defects Check RAP
• IQ18 DADF Lead Edge Offset RAP
• IQ19 Poor Registration RAP
• IQ20 Skew RAP
IQ1 Internal Test Patterns
Table 1 defines the image defect, gives a description of the defect and identifies the optimum
test pattern to be used.
NOTE: There are 19 internal test patterns, but only 7 are unique. Each test pattern is available
more than one time. Only the first occurrence of a test pattern is shown in
Table 1.
Table 2 describes the test patterns and the purpose for which they should be used to identify
image quality defects.
Table 1 Image quality defects
Image quality
defect
Description of defect
Optimum
internal test
pattern
Background Uniform darkening across all the non print areas 1
Bands Grey to dark in the light or non-image areas of the print in the
process direction or across the process direction. See also
narrow bands.
1
Beads on print Developer beads in the light or non-image areas of the print. 1, 7, 8
Black image A print that is black or grey all over, but has no visible image
of the original document.
1, 7, 8
Blank image No visible image. 1, 7, 8
Blurred image Part or whole of the image has the appearance of being out
of focus.
1, 7, 8
Dark prints Very dark background with a visible image. 1, 7, 8
Deletions Areas of the image missing from the print. Deletions may be
in the form of white spots, marks, lines, or whole areas of
toner missing from the print.
1, 6
Displaced and
fragmented
Distorted images, part images and missing images (scram-
bled images). Displaced images.
1
Light image The image is visible on the print, but with insufficient solid
area density.
1
Lines Black or white lines across the process direction or in the pro-
cess direction. See also the description, displaced and frag-
mented image.
1, 7
Magnification At 100% magnification the printed image differs from the size
of the image on the original document.
7
Marks Dark marks in the non-image areas of the print. 1, 7
Misregistration The image on the paper is misregistered. 7
Narrow Bands Bands across the process direction visible in halftone areas. 1, 4, 5
Non uniformity Variation in image quality and density across the print. See
also uneven density.
4, 5
Offsetting A previous image that was not removed from the fuser roll
during the cleaning cycle. The image is repeated at regular
intervals.
1, 5
