Phaser 3635MFP/WorkCentre 3550
REP 3.1
Repairs and Adjustments
REP 3.1 Main PWB
Parts List on PL 3.10
Removal
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
WARNING
Take care during this procedure. Sharp edges may be present that can cause injury.
CAUTION
Before performing this procedure, refer to GP 10 General Disassembly Precautions.
CAUTION
Ensure that E.S.D. procedures are observed during the removal and installation of the main
PWB. Make a visual check to ensure that the pins are fully inserted, without being damaged.
1. If a new main PWB is to be installed, go to GP 3 Machine Status. If possible, print the fol-
lowing reports:
• System Configuration.
• Local Address Book Members.
• Group Address Book Members.
2. Remove the left cover, REP 28.1.
CAUTION
3635 only. Take care to identify the connections to the Main PWB. The 4 pin connectors are
interchangable.
• CN4, 4 wires: 3 grey, 1 black.
• CN5, 3 wires: 2 grey, 1 black.
• CN17, 4 wires: 3 grey, 1 black.
• CN18, not used.
• CN36, 4 wires: 2 grey 2 black.
3. Unplug all the connectors from the main PWB, PL 3.10 Item 6.
4. Remove the MSOK, PL 3.10 Item 14.
5. Remove the memory DIMM, PL 3.10 Item 10.
6. Remove the SIM card holder, PL 3.10 Item 8.
7. If installed, remove the foreign device interface PWB, PL 3.10 Item 7.
8. Remove 5 screws, then the main PWB, PL 3.10 Item 6.
Replacement
1. Replacement is the reverse of the removal procedure.
2. If a new main PWB has been installed, perform the following:
a. Install the MSOK onto the new main PWB, PL 3.10 Item 14.
b. Install the memory DIMM onto the main PWB, PL 3.10 Item 10.
c. Perform a Memory Clear, refer to OF7 Main PWB Check RAP Software Checks.
d. Use the information on the printed lists to re-enter the customer’s settings. Refer to
GP 4 System Administration Tools.
3. If the machine has a communication fault after the replacement of the main PWB,
upgrade the firmware,
GP 6 Firmware Upgrade.
