Xerox WorkCentre 3550 - IQS 2 Skew; IQS 3 Registration

April 2010
3-22
Phaser 3635MFP/WorkCentre 3550
IQS 2, IQS 3
Image Quality
IQS 2 Skew
Documents
Test pattern: 82E2020 (8.5 x 11) or 82E2010 (A4).
Specification
Refer to Table 1.
IQS 3 Registration
Documents
Test pattern: 82E2020 (8.5 x 11) or 82E2010 (A4).
Specifications
Refer to Table 1.
Corrective Action
Go to the IQ19 Poor Registration RAP.
Table 1 Skew specifications
Skew Specification
Print Skew Max: +/-2.5mm (7/64 inch) per 250mm (10 inches) (+/-1%)
Table 1 Registration measurement
Registration Specification
Lead edge 4mm (5/32 inches) +/- 3mm (1/8 inches)
Top edge 4mm (5/32 inches) +/- 3mm (1/8 inches)
