Page #201 background imageLoading...
Page #201 background image
April 2010
6-40
Phaser 3635MFP/WorkCentre 3550
dC132
General Procedures/Information
dC132 NVM Initialization
Refer to the relevant section:
NVM Initialization - Copier
NVM Initialization - Network (3635 only)
NVM Initialization - Fax Card
NVM Initialization - Copier
Purpose
To return the copier NVM settings to default. Refer to dC131 NVM Read/Write.
Refer to the relevant section:
NVM Initialization - Copier Procedure (3635)
NVM Initialization - Copier Procedure (3550)
NVM Initialization - Copier Procedure (3635)
1. Enter diagnostics, GP 1 Diagnostics Entry.
2. Select Diagnostic Routines.
3. Select Copier Routines, then 132 NVM Initialization - Copier.
4. Touch the appropriate button to select the NVM to be initialized and follow the screen
instructions. Refer to
Table 1, for the functions that are reset to default:
All Copier NVM
Machine Variable NVM
SA/KO Dust Off
System Counters Dust Off
5. Switch off the machine, then switch on the machine.
NVM Initialization - Copier Procedure (3550)
1. Enter diagnostics, GP 1 Diagnostics Entry.
2. Select Machine Diagnostics and press the OK key.
3. Select EDC Mode and press the OK key.
4. Select DC132 NVM Initialization and press the OK key.
5. Select Yes and press the OK key to confirm initialization of the NVM values. All NVM will
be reset to default.
NVM Initialization - Network (3635 only)
Purpose
To reset the network settings to default.
Procedure
1. Enter diagnostics, GP 1 Diagnostics Entry.
2. Select Diagnostic Routines.
3. Select Network Routines, 132 NVM Initialization - Network, then All Network NVM.
4. Follow the screen instructions to reset the network settings.
5. Switch off the machine, then switch on the machine.
NVM Initialization - Fax Card
Purpose
To return the fax card NVM settings to default. Refer to dC131 NVM Read/Write.
Refer to the relevant section:
NVM Initialization - Fax Card Procedure (3635)
NVM Initialization - Fax Procedure (3550)
NVM Initialization - Fax Card Procedure (3635)
1. Enter diagnostics, GP 1 Diagnostics Entry.
2. Select Diagnostic Routines.
3. Select Fax dC Routines, then 132 NVM initialisation.
4. Touch the appropriate button to select the NVM to be initialized and follow the screen
instructions. Refer to
Table 2, for the functions that are reset to default.
Kill All
All Fax Directories
Table 1 Copier NVM (3635)
Copier file type Category
All Copier
NVM
Machine
Variable NVM
SA/KO Dust
Off
System
Counters
Dust Off
NVM System Usage Counter Y Y
NVM Fault Counter Y Y
NVM Diag Counter Y Y
NVM SAKO Setting Y Y
NVM Fault Log Y
NVM Configuration Y
NVM Diagnostics Y
NVM Debug Y
NVM Mach Var Y Y
NVM Mach Var Zero Y Y
NVM Mach Var Registration Y Y
NVM Mach Var Paper Path Y Y
NVM Mach Var DADF Y Y
NVM Mach Var Platen Y Y
NVM Auditron Y Y
NVM Crash Recovery Y
NVM Completed Job Log Y
NVM JBA Database Y Y
NVM JBA Config Y Y
NVM Auditron Config Y Y
NVM HFSI Counter N N N N
Table 1 Copier NVM (3635)
Copier file type Category
All Copier
NVM
Machine
Variable NVM
SA/KO Dust
Off
System
Counters
Dust Off
