April 2010
6-43
Phaser 3635MFP/WorkCentre 3550
dC330
General Procedures/Information
iv. Low
v. A numeric value with up to four digits e.g. 0020.
6. Touch a component in the component table and then touch Stop to stop that component.
To stop all components touch Stop All.
7. Touch Exit to close the Component Control window.
8. To exit diagnostics mode, GP 1 Diagnostics Entry, select the Call Close Out button.
3550 Component Control
1. Enter diagnostics, GP 1 Diagnostics Entry.
2. For fax component control:
a. Select Fax Diagnostics and press the OK key.
b. Select EDC Mode and press the OK key.
c. Select DC330 CC and press the OK key.
3. For machine component control:
a. Select Machine Diagnostics and press the OK key.
b. Select EDC Mode and press the OK key.
c. Select DC330 Component Control and press the OK key.
4. Select the required control code and press the OK key.
5. Press the OK key to start a component. Press the Stop key to stop the component.
6. Press the Return key to close the Component Control window.
7. Exit diagnostics mode, GP 1 Diagnostics Entry.
Input Codes
Table 1 Input codes 01
Code Displayed Name Description General
01-100 Front cover inter-
lock
Front cover interlock switch (S01-
100), detects if the side cover is
open.
Closed = front cover closed
Opened = front cover
opened
Table 2 Input codes 05
Code Displayed Name Description General
05-100 DADF Doc. Detect
Sensor
DADF document detect sensor
(Q05-100), detects if a document is
present.
High = document present
Low = no document
05-120 DADF Paper
Length Sensor
DADF paper length sensor (Q05-
120), (Q05-100), detects if a docu
-
ment is present.
High = document present
Low = no document
05-130 DADF Registration
Sensor
DADF document registration sen-
sor (Q05-130), detects if a docu-
ment is present.
High = document present
Low = no document
05-140 DADF Scan Sensor DADF document scan sensor
(Q05-140), detects if a document is
present.
High = document present
Low = no document
05-160 DADF Door Open
Sensor
DADF door open sensor (Q05-
150), detects if the DADF door is
open.
High = door open
Low = door closed
Table 3 Input codes 06
Code Displayed Name Description General
06-110 LSU Motor Ready Detects if the LSU motor (MOT06-
100) is running at normal speed.
High = not running at nor-
mal speed
Low = running at normal
speed
Table 4 Input codes 07
Code Displayed Name Description General
07-110 T1 Paper Empty
Sensor
Tray 1 paper empty sensor (Q07-
110), detects if there is paper
present in tray 1.
High = tray empty
Low = paper present
07-210 T2 Paper Empty
Sensor
Tray 2 paper empty sensor (Q07-
210), detects if there is paper
present in tray 2.
High = tray empty
Low = paper present
07-510 Bypass Paper
Empty Sensor
Bypass paper present sensor (Q07-
510), detects if there is paper
present in the bypass tray.
High = Tray empty
Low = Paper present
Table 5 Input codes 08
Code Displayed Name Description General
08-100 Feed Sensor Detects when the lead edge of the
paper is at the feed sensor (Q08-
100).
High = paper present
Low = no paper
08-500 Regi. Sensor Detects when the lead edge of
paper is at the registration sensor
(Q08-500).
High = paper present
Low = no paper
08-600 Exit Sensor Detects when the lead edge of
paper is at the fuser exit sensor
(Q08-600).
High = paper present
Low = no paper
08-700 Duplex Jam 1 Sen-
sor
Detects when there is paper at the
duplex jam 1 sensor (Q08-700).
High = paper present
Low = no paper
08-720 Out-Bin Full Sensor Detects when the paper is at the
out bin full sensor (Q08-720).
High = paper present
Low = no paper
Table 6 Input codes 09
Code Displayed Name Description General
09-310 THV Bias Read Detects the THV value on the
transfer roller.
Displays THV value =
XXX
Table 7 Input codes 10
Code Displayed Name Description General
10-200 Fuser Temperature
A
Measures the fuser temperature at
the thermistor.
Displays temperature in
degrees C = XXX
