ENGINE UNIT
ENGINE UNIT
EXPLODED DIAGRAM
REMOVAL AND INSTALLATION CHART
Step Procedure/Part name Q’ty Service points
ENGINE UNIT REMOVAL
Follow the left “Step” for removal.
Engine oil Drain.
Refer to “POWER UNIT” in Chapter 3.
Service lid 1 Refer to “FRONT HOOD” in Chapter 8.
Battery negative and positive lead Refer to “ELECTRICAL BOX” in Chapter 7.
Throttle cable and fuel hose Refer to “FUEL INJECTION SYSTEM” in
Chapter 4.
Water lock and exhaust joint Refer to “EXHAUST SYSTEM” in Chapter 8.
1 Oil filter 1
2Bolt 4
4
10
11
12
6
3
7
2
8
1
9
5
9
14
9
13
15
LT
271
LT
LT
572
LT
7.8 N
•
m (0.78
kgf • m, 5.6 ft • Ib)
6 × 25 mm
8 × 28 mm
17 N • m (1.7
kgf
•
m, 12 ft
•
Ib)
17 N • m (1.7
kgf
•
m, 12 ft
•
Ib)
8 × 40 mm
17 N • m (1.7
kgf
•
m, 12 ft
•
Ib)
LT
572
LT
