Yamaha WaveRunner - Fuel Injection System

4-8
E
FUEL
FUEL INJECTION SYSTEM
FUEL INJECTION SYSTEM
EXPLODED DIAGRAM
REMOVAL AND INSTALLATION CHART
Step Procedure/Part name Q’ty Service points
THROTTLE BODIES REMOVAL
Follow the left “Step” for removal.
1Screw 2
2 Air filter case cover 1
3 Air filter 1
4Bolt 4
5 Ribbon sub assembly 2
6 Holder 2
7 Throttle cable 1
8Bolt 2
9 Throttle cable holder 1
10 Cover 1
LT
572
LT
LT
242
LT
E
AA
LT
572
LT
LT
572
LT
7
8
9
15
14
12
13
11
10
5 × 70 mm
2.5 N • m (0.25 kgf • m, 1.8 ft • Ib)
6 × 7 mm
6.5 N • m (0.65 kgf • m, 4.7 ft • Ib)
8 × 50 mm
22 N • m (2.2 kgf • m, 16 ft • Ib)
19
19
22
20
21
18
23
17
4 × 8 mm
3.3 N • m (0.33
kgf
•
m, 2.4 ft
•
Ib)
6 × 14 mm
7.6 N • m (0.76
kgf
•
m, 5.5 ft
•
Ib)
3
2
16
6
5
6
4
1
