7-1
E
– +
ELEC
ELECTRICAL COMPONENTS
ELECTRICAL COMPONENTS
L
M
K
J
I
G
F
E
D
C
B
A
0
9
8
7
6
5
4
3
2
1
H
1 Thermoswitch (engine)
2 Starter motor
3 Engine temperature sensor
4 Spark plugs and ignition coils
5 Electrical box
6 Battery
7 Speed sensor
8 Electric bilge pump
9 Cam position sensor
0 Fuel injectors
A Thermoswitch (exhaust)
B Oil pressure switch
C Sensor assembly
D Bypass valve motor
E Throttle position sensor
F Lighting coil and pickup coil
G Engine stop switch, engine
shut-off switch, and start
switch
H Steering switch
I Buzzer
J Fuel pump
K Fuel sender
L Multifunction meter
M Remote control unit
