ELECTRICAL ANALYSIS
ELECTRICAL ANALYSIS
INSPECTION
CAUTION:
• All measuring instruments should be han-
dled with special care. Damaged or mis-
handled instruments will not measure
properly.
• On an instrument powered by dry batter-
ies, check the battery’s voltage periodi-
cally and replace the batteries if
necessary.
Digital tester
NOTE:
Throughout this chapter the part numbers of
the specified digital testers have been omitted.
Refer to the following part numbers.
NOTE:
“” indicates a continuity of electricity;
i.e., a closed circuit at the respective switch
position.
Digital multimeter:
YU-34899-A
Digital circuit tester:
90890-03174
