THERMOSTAT
THERMOSTAT
EXPLODED DIAGRAM
REMOVAL AND INSTALLATION CHART
Step Procedure/Part name Q’ty Service points
THERMOSTAT REMOVAL
Follow the left “Step” for removal.
1 Band 1
2 Clamp/cooling water hose 1/1
È
For cooling water outlet on stern side.
3 Clamp/cooling water hose 2/1
4 Clamp/cooling water hose 1/1
É
For cooling water pilot outlet on starboard
side.
5 Band/grease hose 1/1
6Bolt 2
7 Thermostat housing cover 1
8 Thermostat 1
3
1
3
10
8
7
4
6
5
2
LT
572
LT
572
6 × 35 mm
2nd 7.6 N • m (0.76
kgf
•
m, 5.5 ft
•
Ib)
1st 3.7 N • m (0.37
kgf
•
m, 2.7 ft
•
Ib)
È
É
6 × 70 mm
2nd 7.6 N • m (0.76
kgf
•
m, 5.5 ft
•
Ib)
1st 3.7 N • m (0.37
kgf
•
m, 2.7 ft
•
Ib)
LT
572
LT
572
13
12
11
12
5.9 N • m (0.59 kgf • m, 4.3 ft • Ib)
9
