Yamaha WaveRunner - Exhaust System

8-43
E
HULL
HOOD
EXHAUST SYSTEM
EXHAUST SYSTEM
EXPLODED DIAGRAM
REMOVAL AND INSTALLATION CHART
Step Procedure/Part name Q’ty Service points
EXHAUST SYSTEM REMOVAL
Follow the left “Step” for removal.
Deck beam Refer to “SEATS AND HAND GRIP”.
Jet pump unit assembly Refer to “JET PUMP UNIT” in Chapter 6.
NOTE:
When removing the water lock and exhaust
joint, it is not necessary to remove the jet
pump unit.
1 Band 1
2 Joint clamp 1
3 Hose clamp 1
4 Water lock 1
7
14
3
13
15
18
17
12
11
16
10
5
1
4
3.7 N • m (0.37
kgf
•
m, 2.7 ft
•
Ib)
5.4 N
•
m (0.54
kgf • m, 3.9 ft • Ib)
2.5 N • m (0.25
kgf
•
m, 1.8 ft
•
Ib)
3.7 N • m (0.37
kgf
•
m, 2.7 ft
•
Ib)
6
2
3.7 N • m (0.37
kgf
•
m, 2.7 ft
•
Ib)
3.7 N • m (0.37
kgf
•
m, 2.7 ft
•
Ib)
8
9
