Yamaha WaveRunner - Display Function

7-47
E
– +
ELEC
INDICATION SYSTEM
Display function
1. Check:
• Display function
Does not operate
→
Replace the multi-
function meter.
B/LB
L/R
B/Y
B/YR/W
P
B
R/W
Y
Y
R
R
W
W
B
B
B
P
L/R
R
B
R
1
2
3
4
5
Gy
L/B
L/R
L/Y
L/B
B/L
1 Remote control unit
2 Buzzer
3 Speed sensor
4 ECM
5 Fuel sender
B: Black
Gy : Gray
P: Pink
R: Red
W: White
Y : Yellow
B/G : Black/green
B/L : Black/blue
B/Y : Black/yellow
L/B : Blue/black
L/R : Blue/red
R/W : Red/white
