Yamaha WaveRunner - Steering Cable Installation

92
E
HULL
HOOD
REMOTE CONTROL CABLES AND
SPEED SENSOR LEAD
SERVICE POINTS
Steering cable installation
1. Install:
• Steering cable
Installing steps:
• Connect the cable joint
1
to the ball joint
2
.
• Insert the projection
3
on the steering
cable completely into the indentation
4
in the steering stopper.
• Slightly lift up the steering stopper plate
5
on the steering stopper, and then
rotate it clockwise.
• Rotate the steering stopper plate
6
on
the steering stopper counterclockwise,
making sure to fit the hole in the stopper
plate
6
onto the projection
7
on the
other steering stopper plate
5
.
3
4
6
5
5
7
6
