HULL
HOOD
FRONT HOOD
FRONT HOOD
EXPLODED DIAGRAM
REMOVAL AND INSTALLATION CHART
Step
Procedure/Part name
Q’ty Service points
FRONT HOOD REMOVAL
Follow the left “Step” for removal.
1 Nut/washer 4/4
2 Front hood assembly 1
3Bolt 4
4Bolt 2
5 Hinge assembly 1
6Bolt 2
7 Hood lock assembly 1
8Rivet 4
9 Service lid 1 1
2
7
6
4
8
9
3
5
1
11
10
6 × 30 mm
6.4 N
•
m (0.64
kgf • m, 4.6 ft • Ib)
LT
242
LT
242
6 × 18 mm
5.4 N • m (0.54
kgf
•
m, 3.9 ft
•
Ib)
6 × 18 mm
5.4 N • m (0.54
kgf
•
m, 3.9 ft
•
Ib)
5.4 N
•
m (0.54
kgf • m, 3.9 ft • Ib)
LT
242
