9-4
E
TRBL
ANLS
TROUBLE ANALYSIS
TROUBLE ANALYSIS
NOTE:
Before consulting the “TROUBLE ANALYSIS CHART,” check the following items.
1. Check that the battery is charged and that its specified gravity is within specification.
2. Check that there are no incorrect wiring connections.
3. Check that all wiring connections are properly secured and that they are not rusty.
4. Check that the engine shut-off cord (lanyard) is connect to the engine shut-off switch.
5. Check that fuel is reaching the throttle bodies.
TROUBLE ANALYSIS CHART
Trouble mode Check elements
ENGINE WILL NOT START
HARD STARTING
ROUGH IDLING
HIGH IDLING
ENGINE STALLS
POOR ACCELERATION
ENGINE WILL NOT STOP
POOR PERFORMANCE
LIMITED ENGINE SPEED
OVERHEATING
LOW OIL PRESSURE
LOOSE STEERING
BILGE INCREASE
IRREGULAR WARNING INDICATION
POOR BATTERY CHARGING
Relative part
Reference
chapter
FUEL SYSTEM
Fuel tank 4
Fuel tank breather hose 4
Fuel hose 4
Fuel filter 4
Fuel pump 4
Fuel injectors 4
Trolling speed 3
Air filter 3
To Next Page
