Yamaha WaveRunner - Bilge Strainer Inspection; Electric Bilge Pump Strainer Inspection

3-28
E
INSP
ADJ
BILGE PUMP
BILGE PUMP
Bilge strainer inspection
1. Inspect:
• Bilge strainer
Contaminants
→
Clean.
Cracks/damage
→
Replace.
Inspection steps:
• Remove the deck beam.
Refer to “SEATS AND HAND GRIP” in
Chapter 8.
• Remove the coupling cover.
• Disconnect the bilge strainer case
1
from the bilge strainer.
• Inspect the bilge strainer.
• Install the coupling cover.
• Install the deck beam.
Refer to “SEATS AND HAND GRIP” in
Chapter 8.
1
Electric bilge pump strainer inspection
1. Inspect:
• Cap
• Strainer
Contaminants
→
Clean.
Inspection steps:
• Remove the band
1
.
• Remove the cap
2 and strainer 3.
• Inspect the cap and strainer.
• Install the strainer and cap.
• Install the band.
1
3
2
