CABLE AND HOSE ROUTING
CABLE AND HOSE ROUTING
DOWN
BOW
20˚
DOWN
UP
+
I
H-H
G-G
F-F
I
H
H
G
G
E
B
D
AA
B-B
A-A
C-C
E-E
D-D
2
3
2
5
4
6
7
6
7
2
9
0
A
B
C
6
9
F
5
4
3
F
F
B
D
C
E
C
1
1
2
4
5
6
G
E
D
8
H
I
1 Steering switch lead
2 Fuel tank breather hose
3 QSTS cable
4 Steering cable
5 Shift cable
6 Speed sensor lead
7 Electrical box lead
8 Cooling water pilot outlet
9 Cooling water pilot outlet hose
0 Cooling water pilot outlet
A Negative battery lead
B Positive battery lead
C Battery
D Throttle cable
E Fuel hose
F Handlebar switch lead
G Electrical bilge pump lead
H Remote control unit lead
I Remote control unit antenna
