Yamaha WaveRunner - Specified Torques

19
E
SPEC
TIGHTENING TORQUES
TIGHTENING TORQUES
SPECIFIED TORQUES
Part to tightened Part name
Thread
size
Q’ty
Tightening torque
Remarks
N•mkgf•mft•lb
Hull and hood
Handlebar cover (for FX/FX High
Output)
Screw M6 4 1.1 0.11 0.8
242
LT
Handlebar cover stay (for FX/FX
High Output)
Bolt M6 2 1.1 0.11 0.8
271
LT
Upper handlebar cover (for FX
Cruiser/FX Cruiser High Output)
Screw M5 8 1.1 0.11 0.8
Lower handlebar cover (for FX
Cruiser/FX Cruiser High Output)
Screw M6 2 5.4 0.54 3.9
242
LT
Steering pad (for FX Cruiser/FX
Cruiser High Output)
Bolt M6 4 1.1 0.11 0.8
271
LT
Handlebar holder Bolt M8 4 20 2.0 14
242
LT
Handle boss cover Screw M6 4 0.9 0.09 0.7
242
LT
QSTS converter Nut — 2 5.4 0.54 3.9
QSTS cable 1 locknut Nut — 1161.612
QSTS cable 2 locknut Nut — 1161.612
Steering master Nut — 4202.014
Speed sensor Screw M5 4 5.2 0.52 3.8
242
LT
Steering cable joint (jet pump side) Nut — 1 6.4 0.64 4.6
Shift cable holder Nut — 2 6.4 0.64 4.6
Shift cable bracket Nut — 2151.511
Steering cable grommet Nut — 1 5.9 0.59 4.3
Speed sensor lead grommet Nut — 1 5.9 0.59 4.3
QSTS cable end pin Nut — 1 3.8 0.38 2.7
QSTS cable grommet Nut — 1 5.9 0.59 4.3
QSTS cable locknut (jet pump side) Nut — 1 2.9 0.29 2.1
572
LT
Shift cable grommet Nut — 1 5.9 0.59 4.3
Shift cable locknut (reverse gate
side)
Nut — 1 2.9 0.29 2.1
572
LT
Hinge assembly Nut — 4 6.4 0.64 4.6
Front hood assembly Bolt M6 6 5.4 0.54 3.9
242
LT
Hood lock assembly Bolt M6 2 5.4 0.54 3.9
242
LT
Front hood Screw M5 8 2.2 0.22 1.6
Visor Bolt M5 6 1.1 0.11 0.8
Mirror assembly
Bolt M6 4 5.4 0.54 3.9
242
LT
Nut — 2 5.4 0.54 3.9
Mirror cover Screw M5 12 3.7 0.37 2.7
Mirror Screw M5 8 3.7 0.37 2.7
Multifunction meter cover Screw M5 4 2.2 0.22 1.6
Multifunction meter Bolt M5 4 3.7 0.37 2.7
Side cover
Bolt M6 8 5.4 0.54 3.9
242
LT
Nut — 2 5.4 0.54 3.9
