Yamaha WaveRunner - Self-Diagnosis

9-8
E
TRBL
ANLS
TROUBLE ANALYSIS
SELF-DIAGNOSIS
With the engine running, press the select but-
ton
1
for 8 seconds and check if an error code
is indicated on the multifunction meter.
If the Yamaha Diagnostic System is not used
to check the symptoms listed in the table, the
error codes can be checked easily with the
self-diagnosis in the multifunction meter. How-
ever, if there are numerous error codes dis-
played, be sure to check them with the
Yamaha Diagnostic System.
Code Symptom
01 Normal
13 Pickup coil malfunction
15
Engine temperature sensor
malfunction
18
Throttle position sensor
malfunction
19 Incorrect battery voltage
23
Intake air temperature sensor
malfunction
24 Cam position sensor malfunction
29
Intake air pressure sensor
malfunction
47 Slant detection switch malfunction
48 Incorrect data transmission
54 Bypass valve motor malfunction
55 Steering switch malfunction
63 Intake air system malfunction
1
