53
E
– +
ELEC
OFF THROTTLE STEERING SYSTEM
STEERING SENSOR
1. Check:
• Steering sensor
Malfunction
→
Replace the steering
sensor.
Checking steps:
• Turn the handlebar all the way to the left
or right, and then release it.
• Install a plastic tie
1
loosely around the
center of the handlebar grip as shown.
• Hook a spring gauge
2
onto the plastic
tie.
• Hold the spring gauge at a 90° angle
from the handlebar, and then pull the
spring gauge with a force of 10 kgf
(22 lb).
When handlebar
pulled
When handlebar
not pulled
ON OFF
• Check that the following is displayed in
the “Engine Monitor” window of the
Yamaha Diagnostic System.
• Use the same procedure to check that
the steering sensor operates correctly
when the handlebar is turned to both the
left and right. Replace the steering sen-
sor if it is a malfunction.
1
2
