Yamaha WaveRunner - Page 482

94
E
HULL
HOOD
FRONT HOOD
EXPLODED DIAGRAM
Step
Procedure/Part name
Q’ty Service points
10 Rivet 4
11 Service lid 2 1
Reverse the removal steps for installation.
2
7
6
4
8
9
3
5
1
11
10
6 × 30 mm
6.4 N
•
m (0.64
kgf • m, 4.6 ft • Ib)
LT
242
LT
242
6 × 18 mm
5.4 N • m (0.54
kgf
•
m, 3.9 ft
•
Ib)
6 × 18 mm
5.4 N • m (0.54
kgf
•
m, 3.9 ft
•
Ib)
5.4 N
•
m (0.54
kgf • m, 3.9 ft • Ib)
LT
242
