5-3
E
POWR
ENGINE UNIT
EXPLODED DIAGRAM
*: As required.
Step Procedure/Part name Q’ty Service points
13 Bolt/washer 4/4
14 Shim *
15 Engine unit 1
Reverse the removal steps for installation.
4
10
11
12
6
3
7
2
8
1
9
5
9
14
9
13
15
LT
271
LT
LT
572
LT
7.8 N
•
m (0.78
kgf • m, 5.6 ft • Ib)
6 × 25 mm
8 × 28 mm
17 N • m (1.7
kgf
•
m, 12 ft
•
Ib)
17 N • m (1.7
kgf
•
m, 12 ft
•
Ib)
8 × 40 mm
17 N • m (1.7
kgf
•
m, 12 ft
•
Ib)
LT
572
LT
E
