Yamaha WaveRunner - Page 151

5-42
E
POWR
GENERATOR AND STARTER MOTOR
EXPLODED DIAGRAM
Step Procedure/Part name Q’ty Service points
8 Pulser coil coupler 1
9Nut 2
10 Bolt 8
11 Generator cover 1
12 Dowel pin 2
13 Gasket 1
14 Idle gear shaft 1
15 Idle gear 1
16 Bolt/washer 1/1
17 Flywheel magneto 1
18 Bolt 6
4
3
2
1
5
6
8
7
9
10
11
13
12
18
16
17
19
20
21
15
14
AA
E
E
E
LT
572
LT
572
AA
AA
8 × 30 mm
18 N • m (1.8
kgf
•
m, 13 ft
•
Ib)
4.9 N
•
m (0.49
kgf • m, 3.5 ft • Ib)
10 × 47 mm
75 N • m (7.5
kgf
•
m, 54 ft
•
Ib)
8 × 20 mm
24 N • m (2.4
kgf
•
m, 17 ft
•
Ib)
10 × 60 mm
2nd 50 N • m (5.0
kgf
•
m, 36 ft
•
Ib)
1st 15 N • m (1.5
kgf
•
m, 11 ft
•
Ib)
LT
572
LT
572
2nd 50 N • m (5.0
kgf
•
m, 36 ft
•
Ib)
1st 15 N • m (1.5
kgf
•
m, 11 ft
•
Ib)
Not reusable
Not reusable
