Yamaha WaveRunner - Page 173

5-64
E
POWR
CYLINDER HEAD
EXPLODED DIAGRAM
Step Procedure/Part name Q’ty Service points
4 Nut/washer 2/2
5 Nut/washer 6/6
6 Nut/washer 2/2
7 Cylinder head 1
8 Cylinder head gasket 1
9 Dowel pin 2
Reverse the removal steps for installation.
E
E
E
E
E
E
2
4
1
8
5
5
7
9
3
5
5
6
LT
271
2nd 121 ± 5˚
1st 20 N • m (2.0
kgf
•
m, 14 ft
•
Ib)
2nd 140 ± 5˚
1st 20 N • m (2.0
kgf
•
m, 14 ft
•
Ib)
10 N
•
m (1.0
kgf • m, 7.2 ft • Ib)
6 × 12 mm
10 N
•
m (1.0
kgf • m, 7.2 ft • Ib)
6 × 55 mm
10 N
•
m (1.0
kgf • m, 7.2 ft • Ib)
6 × 12 mm
40 N
•
m (4.0
kgf • m, 29 ft • Ib)
8 × 20 mm
5
2nd 105 ± 5˚
1st 20 N • m (2.0
kgf
•
m, 14 ft
•
Ib)
E
Not reusable
