2-8
E
SPEC
MAINTENANCE SPECIFICATIONS
*1 The figures are for reference only.
Starter relay
Rating Seconds 30
Thermoswitch
ON temperature (engine) °C (°F) 84–90 (183–194)
OFF temperature (engine) °C (°F) 70–84 (158–183)
ON temperature (exhaust) °C (°F) 94–100 (201–212)
OFF temperature (exhaust) °C (°F) 80–94 (176–201)
Engine temperature sensor
Engine temperature sensor
resistance (B/Y – B/Y)
@ 20 °C (68 °F) k
Ω
54.2–69.0
@ 100 °C (212 °F) k
Ω
3.12–3.48
Speed sensor
Output voltage (on pulse) V 11.6
Output pulse/one full turn 2
Throttle position sensor
Output voltage (P – B/O)
@ trolling speed V 0.756
±
0.016
Cam position sensor
Output voltage (G/O – B/O)
Position A V More than 4.8
Position B V Less than 0.8
Position C V More than 4.8
Fuel sender
Fuel sender resistance
Position A
Ω
133.5–136.5
Position B
Ω
5–7
Oil pressure switch
Oil pressure switch continuity
pressure
kPa
(kgf/cm
2
, psi)
128 (1.28, 18.2)–166 (1.66, 23.6)
Fuel injector
Fuel injector resistance
*1
Ω
11.5–12.5
Fuse
Rating
Main V/A 12/20
Remote control unit V/A 12/3
Electrical bilge pump V/A 12/3
Item Unit
Model
FX High Output
FX Cruiser High Output
