7-40
E
– +
ELEC
ELECTRIC BILGE PUMP
ELECTRIC BILGE PUMP
1. Check:
• Electric bilge pump operation
Incorrect
→
Replace.
Checking steps:
• Suspend the electric bilge pump in a con-
tainer filled with water.
• Connect the brown lead terminal to the
positive battery terminal.
• Connect the black lead terminal to the
negative battery terminal.
• Check the water flows from the electric
bilge pump hose.
–
+
B
Br
FUSE
Refer to “STARTING SYSTEM”.
BATTERY
Refer to “ELECTRICAL” in Chapter 3.
MAIN AND FUEL PUMP RELAY
Refer to “IGNITION SYSTEM”.
REMOTE CONTROL UNIT
Refer to “REMOTE CONTROL SYS-
TEM”.
To Next Page
