SPEC
TIGHTENING TORQUES
Oil tank – oil tank stay
1st
Nut — 2
2.0 0.2 1.4
572
LT
2nd 15 1.5 11
3rd 39 3.9 28
Oil tank stay – cylinder
head
1st
Bolt M10 2
2.0 0.2 1.4
572
LT
2nd 15 1.5 11
3rd 39 3.9 28
Band/collar – oil tank Bolt M6 1 7.6 0.76 5.5
572
LT
Bracket (coupling cover) –
oil tank
1st
Bolt M6 2
3.7 0.37 2.7
572
LT
2nd 7.6 0.76 5.5
Hanger – oil tank cover
1st
Bolt M6 4
3.7 0.37 2.7
572
LT
2nd 7.6 0.76 5.5
Oil tank cover – oil tank
1st
Bolt M6 8
3.7 0.37 2.7
572
LT
2nd 7.6 0.76 5.5
Oil breather plate 1/
oil breather plate 2 –
oil tank cover
1st
Bolt M5 10
1.9 0.19 1.4
E
2nd 4.4 0.44 3.2
Baffle plate – oil tank
1st
Bolt M5 3
1.9 0.19 1.4
E
2nd 4.4 0.44 3.2
Oil strainer – oil tank
1st
Bolt M6 2
3.7 0.37 2.7
E
2nd 7.6 0.76 5.5
Oil cooler cover – oil tank
1st
Bolt M6 24
3.7 0.37 2.7
572
LT
2nd 7.6 0.76 5.5
Anode – oil tank Screw M4 1 3.7 0.37 2.7
E
Oil pump assembly –
reduction drive gear case
Bolt
M6 5 10 1.0 7.2
572
LT
1st
M8 4
15 1.5 11
2nd 28 2.8 20
Drain plug (engine oil) Bolt M8 1 20 2.0 14
Strainer – reduction drive
gear case
1st
Bolt M6 2
3.7 0.37 2.7
2nd 7.6 0.76 5.5
Oil pump housing cover 1 – oil seal
housing 1
Bolt M8 1 20 2.0 14
Oil pump housing cover 1/oil seal
housing 1/oil pump housing cover 2
– oil pump housing 2
Bolt M8 3 20 2.0 14
Oil pump housing cover 2 – oil seal
housing 1
Screw M4 1 2.0 0.2 1.4
Drive coupling – drive shaft ——128 2.8 20
572
LT
Reduction drive gear case
– crankcase
1st
Bolt M6 2
3.7 0.37 2.7
572
LT
2nd 7.6 0.76 5.5
1st
Bolt M8 5
15 1.5 11
572
LT
2nd 28 2.8 20
Starter motor lead – starter motor Nut — 1 4.9 0.49 3.5
A
Starter motor – crankcase Bolt M8 2 18 1.8 13
Part to tightened Part name
Thread
size
Q’ty
Tightening torque
Remarks
N•mkgf•mft•lb
