8-9
E
HULL
HOOD
QSTS GRIP
EXPLODED DIAGRAM
Step Procedure/Part name Qty Service points
7 Screw/washer 2/2
8 Spacer 1
9 QSTS shift lock lever 1
10 Spring 1
11 Spacer 1
12 Cable housing 1
13 QSTS grip 1
Reverse the disassembly steps for
assembly.
