Yamaha WaveRunner - Page 358

8-45
E
HULL
HOOD
EXHAUST SYSTEM
EXPLODED DIAGRAM
Step Procedure/Part name Q’ty Service points
15 Hose clamp 1
16 Water tank 1
17 Rubber hose 1
18 Plate 1
Reverse the removal steps for installation.
7
14
3
13
15
18
17
12
11
16
10
5
1
4
3.7 N • m (0.37
kgf
•
m, 2.7 ft
•
Ib)
5.4 N
•
m (0.54
kgf • m, 3.9 ft • Ib)
2.5 N • m (0.25
kgf
•
m, 1.8 ft
•
Ib)
3.7 N • m (0.37
kgf
•
m, 2.7 ft
•
Ib)
6
2
3.7 N • m (0.37
kgf
•
m, 2.7 ft
•
Ib)
3.7 N • m (0.37
kgf
•
m, 2.7 ft
•
Ib)
8
9
