Yamaha WaveRunner - Page 41

2-22
E
SPEC
CABLE AND HOSE ROUTING
B
D
G
F
A
E-E
Ð
Ï
Ë
ËË
Ë
Ê
È
É
Õ
Ì
Ñ
Ì
Ó
×
Ñ
Ô
Ì
Ê
Ò
Ò
Ø
Ë
D
A
G
F
B
5
4
1
1
E
E
Í
C-C
Î
3
2
C
C
Ö
Î Bundle the cooling water pilot outlet hose and
cooling water hoses, pass a plastic tie through the
stay hole, and then fasten the tie.
Set the tie in the direction shown.
Ï To cooling water pilot outlet on port side
Ð To cooling water outlet at stern
Ñ Cooling water inlet
Ò To exhaust pipe
Ó To install the cooling water hose, align the white
paint mark on the hose with the parting line on the
hose joint.
Ô Fasten the cooling water hose and negative bat-
tery lead with a plastic tie. Set the tie in the direc-
tion shown.
