1.3 Model Number and Nameplate Check
30 YASKAWA ELECTRIC SIEP C710616 27C YASKAWA AC Drive A1000 Technical Manual
Three-Phase 200 V
Three-Phase 400 V
Note: Refer to Drive Models and Enclosure Types on page 31 for differences regarding enclosure protection types and component
descriptions.
Normal Duty Heavy Duty
No.
Max. Motor Capacity
kW
Rated Output
Current A
No.
Max. Motor Capacity
kW
Rated Output
Current A
0004 0.75 3.5 0004 0.55 3.2
0006 1.1 6.0 0006 1.1 5
0010 2.2 9.6 0010 1.5 8
0012 3.0 12 0012 2.2 11
0021 5.5 21 0021 4.0 17.5
0030 7.5 30 0030 5.5 25
0040 11 40 0040 7.5 33
0056 15 56 0056 11 47
0069 18.5 69 0069 15 60
0081 22 81 0081 18.5 75
0110 30 110 0110 22 85
0138 37 138 0138 30 115
0169 45 169 0169 37 145
0211 55 211 0211 45 180
0250 75 250 0250 55 215
0312 90 312 0312 75 283
0360 110 360 0360 90 346
0415 110 415 0415 110 415
Normal Duty Heavy Duty
No.
Max. Motor Capacity
kW
Rated Output
Current A
No.
Max. Motor Capacity
kW
Rated Output
Current A
0002
<1> Contact Yaskawa for information about using drives in environments other than specified in this manual.
0.75 2.1 0002 0.55 1.8
0004 1.5 4.1 0004 1.1 3.4
0005 2.2 5.4 0005 1.5 4.8
0007 3.0 6.9 0007 2.2 5.5
0009 4.0 8.8 0009 3.0 7.2
0011 5.5 11.1 0011 4.0 9.2
0018 7.5 17.5 0018 5.5 14.8
0023 11 23 0023 7.5 18
0031 15 31 0031 11 24
0038 18.5 38 0038 15 31
0044 22 44 0044 18.5 39
0058 30 58 0058 22 45
0072 37 72 0072 30 60
0088 45 88 0088 37 75
0103 55 103 0103 45 91
0139 75 139 0139 55 112
0165 90 165 0165 75 150
0208 110 208 0208 90 180
0250 132 250 0250 110 216
0296 160 296 0296 132 260
0362 185 362 0362 160 304
0414 220 414 0414 185 370
0515 250 515 0515 220 450
0675 355 675 0675 315 605
